Hinged insulated system SMARTIA S67

Description

SMARTIA S67 is the new complete Tilt & Turn system of ALUMIL, which combines outstanding thermal insulation performances along with high construction flexibility and exceptional design.
Add to favorites


Advantages

  • Very good value for money
  • High energy savings due to the high energy efficiency of the system
  • Increased level of security
  • High level of sound insulation
  • Ease of use and high functionality
  • Modern design for windows either with flat or curved line
  • Ease of access according to specifications for people with special needs and children
  • High quality with certified performances
  • Increased static loads and functionality in case of severe weather conditions

Generic

WINDOW TYPES
Hinged

THERMAL INSULATION
Yes

EXTERIOR SHAPES
Flat

Technical Characteristics

FRAME DEPTH
67 mm

SASH DEPTH
75 mm

MINIMUM VISIBLE ALUMINIUM FACE HEIGHT
93 mm

MINIMUM VISIBLE ALUMINIUM FACE WIDTH AT THE CENTRAL VERTICAL COLUMN (ADJOINING PROFILE)
67 mm

GLAZING TYPE
Double – Triple

MAXIMUM GLAZING THICKNESS
up to 58 mm

MECHANISM
Euro-groove, Euro-nut

SEALING METHOD
Perimetrical at 3 levels with EPDM gaskets

MINIMUM THRESHOLD HEIGHT
13 mm

TYPE OF THERMAL INSULATION
30mm fiber glass polyamides, PE insulation Foam

Performance

WATER TIGHTNESS
CLASS Ε1500

AIR PERMEABILITY
CLASS 4

SOUND REDUCTION
45 dB

BURGLAR RESISTANCE
RC2/RC3

Performance

SASH WEIGHT
up to 180 Kg

UF
from 1,1 to 2,6 W/m²K

TYPES OF TYPOLOGY
For all tilt & turn typologies

TYPOLOGIES

Fixed window

Double fixed lights

One sash tilt and turn

Τilt and turn with fix light on top

Τilt and turn with fanlight

Double tilt and turn window

Double tilt and turn window with fixed light

Double tilt and turn with fanlight

Double tilt and turn with fixed lights sideways

Double tilt and turn window with shutter
