SMARTIA M8200 Glass Railings
Description
Vertical glass support system for glass railings of modern aesthetics and top robustness. Continuous base profiles without mullions, to leave the visual field free and offer a sense of luxurious freedom.
Advantages
- Extreme sturdiness due to the continuous profiles
- Easy and fast to install
- Top quality in terms of design and production
- Constructions of great lengths without any glass alignment issues
- Extensive variety in terms of placement, glass thickness, handrails and surface treatment
Generic
PHILOSOPHY
continuous profile with simple wedges
PLACEMENT – INSTALLATION
on-floor, side-mounted, embedded, curved
USE
outdoor, indoor, seaside
APPLICATIONS
modern residences, hotels, malls, commercial and office buildings
Technical Characteristics
GLAZING TYPE
laminate tempered
GLASS THICKNESS
12+12, 10+10, 8+8, 6+6, 5+5 mm
MAXIMUM HEIGHT
1,6 m
MAX STRUCTURE LENGTH
unlimited
HANDRAILS
various shapes (flat, oval, round, square)
END COVERS
inox and coated aluminium
LIGHTING
with 8+8mm glass thickness
PRE-DRILLED PROFILES
yes, and for counter shank screws
Performance
LINEAR HORIZONTAL LOAD
up to 4.0KN/m
Characteristics
WIND LOAD RESISTANCE
up to 5.0KN/m2
Typologies
M8200 on-floor, with a 8+8mm and 10+10mm glass
M8207 on-floor, with 8+8mm and 10+10mm glass
M8209 on-floor, with 5+5mm, 6+6mm and 8+8mm glass up to 70cm height
M8208 on-florr and curved, with 8+8mm and 10+10mm glass
M8202 side-mounted, with 8+8mm and 10+10mm glass
M8210 in-floor, with 8+8mm and 10+10mm glass
M8217, “F” type on-floor base profile with 8+8mm and 10+10mm glass
M8219 “F” type on-floor base profile with 12+12mm glass
